| Quantity: | |
|---|---|
Electrical Characteristics
Nominal Voltage (V) | 12.8V |
Nominal Capacity (Ah) | 100Ah@0.3C 25°C/77° |
Minimum capacity (Ah) | 98Ah@0.3C 25°C/77° |
Nominal Capacity (KWh) | 1280Wh |
Cycle Life | ≥2500 Cycles @0.3C/0.3C |
Serial number | 4S1P |
Charging Parameters
Charge Voltage (V) | 14.4V |
Charge Current (A) | 30A(Recommend) |
Max Charge Current (A) | 50A |
Peak Charge Current (A) | 100A |
Charging Mode | Constant Current /Constant Voltage |
Discharge Parameters
Discharge Cut-off Voltage | 10.8V |
Discharge Current | 50A(Recommended) |
Max Discharge Current | 100A |
Operating Environment
Charge Temperature | 0°C to 55°C,32°F to 131°F |
Discharge Temperature | -20°C to 60°C,-4°F to140°F |
Storage Temperature | 0°C to 40°C,32°F to 104°F |
Other Parameters
Shell Material | ABS+PC |
Battery Size | 330(L) *175(W)*216(H) mm |
Pack Weight | 12Kg |
Protection Class | IP55 |
Internal Resistance | ≤50mΩ @AC 1kHz |
Authentication Level | UN38.3/MSDS |
Usage Note:
1.The charging voltage of the battery shall not exceed the parameters in the specification
2. When the battery is in use, the discharge voltage shall not be lower than the parameters in the specification, othenwise the low-voltage protection may be triggered
3. The charging curent and discharging current of the battery shall not exceed the parameter range of the specification, otherwisethe battery may be damaged
